INS 120
Inclination Sensor — 0–360°, Analog Output, IP64
Inclination Sensor — 0–360°, Analog Output, IP64
The INS 120 is a compact inclination sensor providing a continuous analog output proportional to angle over the full 0–360° range. With IP64 protection and a wide supply voltage range, it suits a broad range of industrial inclination monitoring and control applications where a continuous analog signal is required.
Full 0–360° measuring range — complete revolution coverage
Continuous analog output — 0–10V or 4–20mA proportional to angle
IP64 protection — dust-tight and splash-proof
Wide supply voltage range — 10–30 VDC
Compact housing — easy integration in space-constrained applications
Wide operating temperature — suitable for harsh industrial environments
| Measuring Range | 0–360° |
| Output | Analog (0–10 VDC, 4–20 mA) |
| IP Rating | IP64 |
| Supply Voltage | 10–30 VDC |
| Operating Temperature | −25°C to +70°C |
Contact us for the full technical drawing (PDF)
