INS 130
Angle & Inclination Sensor — 0–360°, Analog or Switching, ±0.15°
Angle & Inclination Sensor — 0–360°, Analog or Switching, ±0.15°
The INS 130 extends the INS 110 by adding continuous analog output. Where the INS 110 provides switching (tilt alarm), the INS 130 delivers a continuous 0–10V or 4–20mA signal proportional to angle, enabling real-time angle monitoring and control. The full 0–360° range with ±0.15° accuracy and IP64 protection makes it suitable for a wide range of industrial inclination applications.
Continuous analog output — 0–10V or 4–20mA proportional to angle
Full 0–360° measuring range — complete revolution coverage
Two-axis (XY) measurement — simultaneous X and Y tilt
±0.15° accuracy — high-resolution inclination measurement
PNP switching also available — tilt alarm function retained
IP64 protection — dust-tight and splash-proof
| Axes | XY (two-axis) |
| Measuring Range | 0–360° |
| Accuracy | ±0.15° |
| Output | Analog (0–10 VDC, 4–20 mA) or PNP switching |
| IP Rating | IP64 |
| Supply Voltage | 10–30 VDC |
| Operating Temperature | −25°C to +70°C |
INS 110 — switching output only (PNP or relay): use for tilt alarms and safety shutdowns.
INS 130 — continuous analog output (0–10V or 4–20mA): use for real-time angle monitoring, display, and closed-loop control. PNP switching variant also available.
